The Stellar Slider hooklift loader is a container handling system mounted on a truck chassis that is capable of loading, unloading and dumping various containers with lengths ranging from 12’ to 18.5’ with the use of a sliding hexagonal jib. The hex jib reduces flex and provides greater structural integrity. The Stellar Slider can accommodate capacities up to 20,000 pounds. The maximum dump angle is 55° with a 54” hook height on a 41-inch high truck frame and below grade capabilities to 46”.
The Stellar Slider20 comes with a standard fixed hook height of 54″ (Optional 61.75″ hook height is available) or a hydraulic adjustable version at 54″ or 61.75″
The Stellar Slider20-S hooklift loader is a container handling system mounted on a truck chassis that is capable of loading, unloading and dumping various containers with lengths ranging from 10′ to 14′ with the use of a sliding hexagonal jib. The hex jib reduces flex and provides greater structural integrity. The Stellar Slider20-S has up to 20,000-pound capacity. The maximum dump angle is 60° with all hook heights on a 40-inch high truck frame.
The Stellar Slider20-S comes with standard fixed hook heights of 35.63″ and 54″ or a hydraulic adjustable version at 35.63″ or 54″.
The Stellar Slider26 hooklift is a container handling system mounted on a truck chassis that is capable of loading, unloading and dumping various containers with lengths ranging from 12’ to 16’ with the use of a sliding hexagonal jib. The hex jib reduces flex and provides greater structural integrity. The Stellar Slider26 can accommodate capacities up to 26,000 pounds. The maximum dump angle is 68° with a 35.63” to 61.75″ hook height.
The Stellar Slider26 comes in a fixed hook height of 35.63″ to 61.75″ or a hydraulic adjustable version at 35.63″ / 54″ and 54″ / 61.75″.
The Stellar Slider34 hooklift is a body handling system mounted on a truck chassis that is capable of loading, unloading and dumping various bodies with lengths ranging from 14′ to 20′ (4267mm to 6096mm) with the use of a hexagonal sliding jib. Now with an adjustable hook height, the Slider34 will handle 54″ (1372mm) or 61.75″ (1568mm) hook height bodies and will accommodate capacities up to 34,000 pounds (15,422kg). The maximum dump angle is 50° on a 41-inch (1,041mm) high truck frame.
The Stellar Slider34 comes with a standard fixed hook height of 54″ (Optional 61.75″ hook height is available) or a hydraulic adjustable version at 54″ or 61.75″.
The Stellar Slider40 hooklift is a body handling system mounted on a truck chassis that is capable of loading, unloading and dumping various bodies with lengths ranging from 12’ to 16’ (3,658 to 4,877 mm) with the use of a hexagonal sliding jib. Now with an adjustable hook height, the Slider40 will handle 54″ (1372mm) or 61.75″ (1568mm) hook height bodies and will accommodate capacities up to 40,000 pounds (18,144kg). The maximum dump angle is 51° on a 43-inch (1,092mm) high truck frame.
The Stellar Slider40 comes with a standard fixed hook height of 54″ (Optional 61.75″ hook height is available) or a hydraulic adjustable version at 54″ or 61.75″.
The Stellar Slider50 Hooklift is a body handling system mounted on a truck chassis that is capable of loading, unloading and dumping various bodies with lengths ranging from 16′ to 22′ (4.9 to 6.7 m) with the use of a hexagonal sliding jib. Now with an adjustable hook height, the Slider50 will handle 54″ or 61.75″ hook height bodies and will accommodate capacities up to 50,000 pounds. The maximum dump angle is 51° on a 45-inch high truck frame.
The Stellar Slider65 Hooklift is a body handling system mounted on a truck chassis that is capable of loading, unloading and dumping various bodies with lengths ranging from 16′ to 21.5′ (4877mm to 6,553mm) with the use of a hexagonal sliding jib. Now with an adjustable hook height, the Slider65 will handle 54″ (1372mm) or 61.75″ (1568mm) hook height bodies and will accommodate capacities up to 65,000 pounds. The maximum dump angle is 50° on a 41-inch (1,041mm) high truck frame.
